Pump Flow Rate is the amount of liquid that passes through its cross-sectional area at a certain time. Gallons per minute (gpm) and cubic meters per hour (m³/h) are common flow rate units.

Understanding and calculating the flow rate is important because it helps determine the right type of pump for different liquids and applications. It also helps determine how much water or liquid a pump can flow through at a given time.

For example, pumps with higher flow rates are suited for commercial or industrial purposes, while lower flow rates work best for domestic use.

Calculating the flow rate of the pump before installation can help you save energy and cost.

In this article, we’ll quickly walk you through the steps to calculate the pump flow rate and explain why it matters.

What Factors Affecting Pump Flow Rate?

Many factors can affect the flow rate of the pumps. These are

1)- Pump Type

The different types of pumps, such as dynamic and displacement pumps, affect flow rates. Positive displacement pumps discharge the water at a constant flow rate, while dynamic pumps affect the flow rates due to changing pressure.

2)- Pump Design And Speed

There are different types of pumps designed to handle various applications. The speed (calculated as rotation per minute) of the pump affects the flow rate. The higher RPM of the pumps discharges liquid with higher flow rates.

3)- Pump Capacity

The pump capacity refers to the maximum volume of fluid handled per unit of time. The large size of pumps has more capacity to discharge large volumes of the liquid. Ensuring proper sealing is also important, as pump seal leakage can lead to fluid loss and make the pump less efficient, reducing its overall capacity.

4)- Fluid Properties

Fluid properties such as density, viscosity, and temperature affect the pump’s flow rates. High-density liquids (heavy liquids) flow more slowly than light-density liquids.

The viscosity of the liquid is defined as its thickness. The temperature change leads to changes in the viscosity of the liquid. Less viscous fluid passes more smoothly than high-viscous liquids.

5)- Pump Size And Length

The various sizes of the pumps affect the flow rates. A large cross-sectional area can produce a high flow rate. The length of the pump also affects the flow rate.

Short-length pumps can produce high flow rates because less resistance occurs in the short pipes. On the other hand, longer pipes create more resistance, slowing the flow of water.

6)- Impeller Characteristics

The impeller’s number of blades, diameter, and rotational speed directly affected the flow rates. Impellers with large diameters and wide blade designs can move more water, leading to higher flow rates.

On the other hand, smaller or narrower blades move less water, resulting in lower flow rates. The number of blades also matters, as it can change how water flows and how efficiently the pump works.

Read More About: Types Of Pump Impellers

7)- Valve Settings

The valves’ design and position affect the pumps’ flow rate. The valves are designed as balls, gates, or globes to impact the flow rates. The opening and closing valves directly affect the flow rates.

8)- System Pressure And Head Pressure

The pressure differences can lead to an increase or decrease in the flow rate of pumps.

9)- Cavitation And NPSH

Cavitation in a pump can generate noise and unstabilise the flow rates. NPSH (net positive suction head) helps remove cavitation from pumps.

Methods To Measure Pump Flow Rate

1)- Through Flow Meter

The flow meter is a simple device that attaches to the discharge outlet to measure the amount of liquid discharged. Flotaa’s Smart Flow Meters are equipped with IoT-enabled ultra-metrologic sensors that help measure pump flow rates easily.

2)- Through Manual Collection

In this method, the water is collected in a bucket or tank. The time it takes to fill the bucket or tanks is calculated, and then the formula helps calculate the flow rate.

The formula for calculating flower rate manually

 Flow rate = Volume of collected liquid / Time Taken

Pump Flow Rate Formula (How To Calculate Pump Flow Rate?)

An exact calculation of the pump flow rate can ensure the understanding of the pump’s efficiency, reliability, and efficiency.

The flow rate of the pump directly depends upon the speed of the pump, impeller size, and density of fluid.

So, the Pump flow rate formula is

Flow rate (Q) = Pump speed x Impeller size x liquid density

Let us understand with data,

a)- Pump speed= 1200 rounds per minute or 20 rounds per second

b)- Impeller size = 8 inches (Typically measured in inches)

c)- Liquid (Water) density = 62.4 pounds per cubic foot (lb/ft³)

Calculations

• For lb/ft³ per minute

Using formula,

Flow Rate (Q) = 1200 (rpm) x 8 (inches) x 62.4 (lb/ft³)

Flow Rate (Q) = 599040 lb/ft³ per minute

• For gallons per minute—GPM

1 cubic foot = 7.48 gallons

Flow rate (GPM) = Flow rate (lb/ft³) / 62.4 (liquid density) x 7.48 gallons

Flow rate (GPM) = 599040/ 62.4 x 7.48 gallons per minute

Flow rate (GPM) = 71808 gallons per minute

• For cubic meters per hour – m³/h

1 cubic foot = 0.0283168 cubic meters

1 minute = 1/60 hour

Flow rate (m³/h) = Flow Rate (lb/ft³ per minute) / Liquid Density x 0.0283168 m³/ft³ x 60 minutes/hour

Flow rate (m³/h) = 599040/62.4 x 0.0283168 x 60 cubic meter per hour

Flow rate (m³/h) = 16,310 cubic meters per hour (approx.)

Tips For Accurate Calculations

The pumps are used in various applications such as irrigation processes, wastewater treatment, chemical industries, energy, oil, and food industries. So, you need to ensure the pump works effectively and efficiently.

Here, we have added some points for accurate calculations.

• First, check the pump specifications, such as maximum flow rate, efficiency, and operational curves.
• Before starting the pump, make sure it is primed and free of air.
• You can get a pump with the desired flow rate by accurate calculation.
• Then, you need to consider how fluid properties such as density and viscosity affect the flow rate of your pump.
• You need to consider the pipe friction that reduces the flow rate of a pump.
• You also need to check the pump performance curve provided by manufacturers, which helps you determine how the flow rate changes at different pressures.
• You can also use the correct formula while calculating the pump flow rate.

Read More About: Self-priming vs Non-Self-priming pumps

How To Improve Pump Flow Rate Efficiency With Flotaa’s Pump Controller

The pump’s efficiency is a concern for users in both domestic and commercial industries.

These pumps can move liquids, gases, and slurries and play critical roles in many industries, such as water treatment, water management, agricultural processes, etc.

Choosing the right pump with an optimal flow rate ensures efficient processes, energy savings, and consistent performance.

Flotaa’s smart pump controller simplifies this process with its IoT-enabled technology and seamless app connectivity. It helps monitor and maintain the correct flow rate, preventing water wastage and optimising pump efficiency. These devices adjust pump speeds based on real-time measurements.

These controllers can control both single- and three-phase pumps and have a range of 1 to 3 kilometres. It connects to your device via apps that help save time and avoid unwanted stress.

For more information or expert guidance, visit Flotaa’s website and get in touch with us.
